30 July 1895
North American roads in the nineteenth century were bad…very bad. Inter-urban “highways” typically consisted of little more than dirt paths carved through the wilderness. In boggy areas, so-called corduroy roads made of logs placed across the direction of travel were sometimes constructed. (They were called corduroy because their texture was reminiscent of corduroy fabric.) If you were very lucky, your highway might be planked, consisting of four-inch thick wooden planks attached to longitudinal stringers. While relatively comfortable on which to drive, planked highways quickly deteriorated. Regardless of road surface, a journey by stagecoach must have been a slow, jolting and painful experience. Coach passengers were also expected to get out and push if their carriage got mired in mud. Needless to say, few travelled by road unless they had to. The true highways of the age were rivers, canals, and later the railway.
Things weren’t a whole lot better in towns. Urban streets, often made of dirt or gravel, were thick with mud when wet, rutted and dusty when dry, and virtually impassable except by sled in winter. In some well-to-do areas, roads were expensively laid with granite blocks known as sett paving. (This type of paving is sometimes called cobblestone paving, though true cobblestone roads were laid with naturally rounded stones set in mortar.) Another more common road surface in North American cities was cedar block paving, consisting of six-inch logs or squared wood set end down on a gravel base. This type of road was cheap but was subject to wear and rot, and lasted for only a few years before needing to be replaced. Cedar block roads were also extremely slippery when wet.
Relief came in the early nineteenth century with the introduction of roadways made by crushed stone developed by two Scottish engineers, Thomas Telford and John McAdam. Telford roads had a base of large rocks with an upper layer of smaller stones. They were also slightly convex to facilitate drainage. McAdam roads eschewed the expensive rock base recommended by Telford, relying instead on a native soil foundation. The roadway was then built up of stones of graduated sizes, the smallest size on top. Typically, no binding agent other than water was applied. Instead the weight of traffic packed down the stone into a durable roadway. McAdam roads became very popular in Europe and North America through the nineteenth century. (When tar was later added as a binding agent, tarmacadam was invented—“tarmac” for short.)
York Street, from Sussex Street to Dalhousie Street, was the first Ottawa roadway to be “macadamized” in June 1851. Forty years later, the Evening Journal described the capital’s streets as consisting of mostly mud or macadam, with a small amount of stone block paving on Bridge Street in LeBreton Flats and cedar block paving on Wellington Street.
Although macadam roadways were effective, they were also costly to maintain. By one estimate, the annual maintenance cost of a macadam road ran to as much as twenty percent of its original cost. This included daily repairs and patches, frequent sprinkling of water as often as three or four times a day to keep down dust, and the regular use of a heavy roller to pack the road down if traffic was insufficient to do so. Not surprisingly, this was not always done, leading to the deterioration of roadways, and complaints from citizens, especially pedestrians, for better roads.
In the late 1800s, the invention of the modern “safety” bicycle (a safe alternative to the preceding high wheeling, penny-farthing bicycle), led to a biking craze. In cities throughout North America and Europe, men and women adopted this new, invigorating and liberating mode of transportation. Not surprisingly, municipal authorities found themselves under heightened pressure to provide smooth road surfaces.
What cities turned to was asphalt. First used in road construction by the ancient Babylonians in around 600 BC, modern asphalt roads date to about the early 1850s in France. Asphalt roads made their way to the United States roughly twenty years later, and to Canada in the mid-1880s. In 1886, a stretch of St James Street (rue Saint Jacques) in Montreal was laid with asphalt paving using asphalt imported from Trinidad. It was a great success. So much so that traffic on parallel streets diverted to use it. The Journal reported that people preferred the “smoothness of asphalt to the vicious wrenchings of the granite or cedar block pavements.” While far more expensive than other forms of paving, asphalt held the promise of durability with an expected life expectancy of fifteen to twenty years, with much less annual maintenance. Asphalt was also viewed as more hygienic, modern, and aesthetically pleasing. As well, horses and carriages were much quieter on asphalt surfaces, reducing the din of urban life.
In 1889, Mr George Perley and Mr William F. Powell submitted a petition to Ottawa’s city council to have Metcalfe Street from Gloucester Street to Gilmour Street paved in asphalt. Apparently, nine of ten landowners on that stretch of road supported the initiative. However, it never came about as city council baulked at their request that an American contractor be brought in to do the paving without putting the job out to tender.
The accolade of being the first asphalted road in Ottawa goes to Sparks Street. This time, a petition of landowners was successful though a vocal minority complained about the cost. In support of conversion, R.J. Devlin, a large retailer on Sparks Street, published a satirical article in the Journal entitled Aye Or No For The Pavement. It read:
No most decidedly! What do we want with a clean, solid and enduring pavement on Sparks street. Haven’t we got on without it in the past? Haven’t we a pretty good street as it is? With the exception of two months in the spring—And six weeks in the fall—And a week now and then every time it rains, Sparks Street is all that could be desired. That is if you wear long boots, Or are handy on stilts. No, gentlemen, we do not want Sparks street paved. What was good enough for our fathers is good enough for us…No, gentlemen, good, plain, everyday mud is good enough for us. It has stuck to us in the past and we will stick to it in the future.
In the end, just over 80% of the landowners by assessed value were in favour, including the Russell House Company, the largest property owner on the block, and W.J. Topley, the noted photographer. The asphalting petition received the City’s Board of Works support and was subsequently approved by City Council in October 1894.
In early 1895, eight bids were received on the contract to pave Sparks and Bank Streets with asphalt. Henry & Smith of Ottawa won with the lowest bid. However, the contract was later cancelled when the company objected to certain terms that the City required. In May 1895, the contract was re-tendered. This time, the Canada Granite Company of Ottawa won with its bid to pave the two streets with rock asphalt from France at a cost of $30,395 and $24,668, respectively. Although another company had provided a slightly lower bid using Trinidad asphalt, the city’s Chief Engineer Robert Surtees rejected it on the grounds that rock asphalt was superior to Trinidad asphalt. (While the original contract called for either grade of asphalt, the second contract specified rock asphalt.) Canada Granite was required to provide a 15-year guarantee, backed up with a blocked deposit worth 30% of the value of the contract. Until the guarantee expired, the company would receive 5 per cent interest from the city on its deposit.
Work on pulling up the old macadam surface of Sparks Street from the corner of Canal Street (now gone but was located roughly where the National Arts Centre is today) to Bank Street began the first week of July 1895 by a team of 60 men and a half a dozen carts. The old stones were re-used to repair the macadam on Somerset Street. The Ottawa Electric Train Company took this opportunity to upgrade its rails on Sparks Street, re-routing its trams onto a temporary track on Wellington Street. Following the laying of a foot-deep foundation, the roadway was ready for paving. On 30 July 1895, Mayor William Borthwick threw onto the road the first shovelful of asphalt at the Sparks and Canal Street corner using a shovel made of polished oak and nickel plate. On one side of the shovel was an engraving of the Parliament Buildings and Ottawa’s City Hall, with a picture of the Granite Company works on the other. There was also a silver inscription that read: “On laying the first asphalt pavement on the streets of Ottawa, junction of Sparks and Canal streets by his Worship William Borthwick, Mayor, July 30, 1895.”
The ceremony was followed by the customary congratulatory speeches with the Mayor saying that Ottawa citizens “would enjoy first class city streets.” Mr C. Strubbe, the Montreal agent for La Compagnie Generale des Asphaltes de France, the supplier of the imported asphalt used in the paving, congratulated City Council and said that the paving shows “the progressive spirit of the people of the capital,” and that it marked an “improvement towards the cleanliness and health of the city.” Afterwards, civic and industry officials repaired to the Russell House Hotel for a light luncheon supplied by the contractor.
It took more than three weeks to complete the Sparks Street paving job, far longer than anticipated leading to grumbles from area merchants who were losing money while the street was under construction. In part, the delays were due to an inexperienced work force. While a number of experienced labourers were brought in from Montreal, many of the workers were inexperienced local men. There was also some labour strife. Local workers were paid only $1.40 per day compared to $2.00 per day being paid to the Montrealers. Ottawa workers briefly went on strike for pay equity, but returned to work when they were promised the Montreal wage rate once they were experienced. To help speed up the work, men laboured at night. However, this proved to be counterproductive as the night work was poorly done. One portion of the street had to be redone three times.
It didn’t help that the work was performed under a microscope, with city councillors and regular citizens alike kibitzing all aspects of the paving job, including whether the asphalt being applied was hot enough, whether the scoria stones used to line the tram rails were being installed correctly, and whether there were sufficient drains. The Journal commented that “every free and independent elector and a large number of embryo members of that class of humanity who passed along Sparks street…appointed himself a special committee of one to inspect and test the small patch of asphalt laid,” by poking it with umbrellas, and walking on it to see how it felt and whether they left heel prints in the dark surface.
Sparks street was finally opened for traffic during the third week of August, though the new paving had already been “initiated” by Moses Inkerman who had driven his rag cart over the unfinished roadway just three days after the Mayor had thrown the first shovelful of asphalt. To celebrate the arrival of asphalt paving, the City sponsored bicycle races on Spark Street from Bank Street to the Russell House Hotel during the evening of Monday, 27 August. Thousands of people watched. The festivities didn’t impress everyone, however. The Journal sniffed that “closing such an important public thoroughfare that four young men might disport themselves on bicycles was in some cases much questioned.”
Criticism of the newly asphalted roadway continued. There was a rash of accidents with horses slipping on the new road surface, which was slippery when wet. One horse died after falling in front of the Russell House Hotel. The Journal opined that drivers were being careless and needed to slow down, but also suggested that horses be taught “the asphalt step.” There were also complaints about cleanliness. Unlike porous macadam surfaces, asphalt roads are impermeable. Consequently, horse waste, of which there was a lot, had no place to go. The Journal thought this factor alone would do much to hasten the arrival of motor vehicles. It stated “To have the streets occupied only by silent, rubber-tired carriages and carts, with little mud and no manure will be an extremely pleasant improvement in city life.” The first automobiles arrived on Ottawa streets four years later.
Despite the many complaints, once Sparks Street was completed, work immediately began on asphalting Bank Street. This was quickly followed by Rideau Street. The asphalt era had arrived. Cyclists, and subsequently cars, had the smooth road surfaces that we now take for granted.
Bradford, Robert, 2015. Keeping Ontario Moving: The History of Roads and Road building in Ontario, Dundurn: Toronto.
Evening Journal (The), 1887, “Our Future Streets,” 19 March.
—————————, 1887. “Street Paving,” 1 August.
—————————, 1889. “Board of Works,” 29 July.
—————————, 1891. “The Paving Of The Streets,” 21 October.
—————————, 1894. “Asphalt In Sight,” 27 September.
—————————, 1894. “The Battle of the Asphalt,” 2 October.
—————————, 1894. “A Foreman For Each Ward,” 29 November.
—————————, 1895. “Is The Asphalting OK?” 26 July.
—————————, 1895. “They All Tested It.” 31 July.
—————————, 1895. “The Mayor Pleased,” 31 July.
—————————, 1895. “Jottings About Town,” 5 August.
—————————, 1895. “Must go Faster.” 5 August.
—————————, 1895. “Points Of Complaint,” 6 August.
—————————, 1895. “Asphalt Pounders Strike,” 6 August.
—————————, 1898. “The Sparks St. Paving,” 9 August.
—————————, 1895. “Passing Of The Horse,” 22 August.
—————————, 1895. “Bike Races On The Asphalt,” 24 August.
—————————, 1895. “The Town Was Out,” 27 August.
—————————, 1895. “The Asphalt Dust,” 27 August.
—————————, 1895. “On Sparks Street,” 31 August.
—————————, 1895. “Died From A Fall,” 7 November.
—————————, 1951. “First Asphalt On Ottawa Streets,” 31 March.
Haig, Robert, 1975, Ottawa: City of the Big Ears, Haig& Haig Publishing Company: Ottawa.
Longfellow, Rickie, 2015. “Back in Time, Building Roads,” Federal Highway Administration.
Mackintosh, Philip G., 2005. “Asphalt Modernism on the Streets of Toronto, 1890-1900,” Material Cultural Review, Volume 62, Fall.
National Asphalt Pavement Association (NAPA), 2017. “The History of Asphalt,”.
Ottawa, City of, 1894. By-laws 1557, “To Provide for a Local Improvement, Asphalt Roadway on Sparks Street”
Rebel Metropolis.org, 2005. “Cedar Blocks and Devil Strips: Cycling the Streets of 1898,” http://rebelmetropolis.org/cedar-blocks-and-devil-strips-cycling-streets-of-1898/.
Story written by James Powell, the author of the blog Today in Ottawa's History.
Retired from the Bank of Canada, James is the author or co-author of three books dealing with some aspect of Canadian history. These comprise: A History of the Canadian Dollar, 2005, Bank of Canada, The Bank of Canada of James Elliott Coyne: Challenges, Confrontation and Change,” 2009, Queen’s University Press, and with Jill Moxley, Faking It! A History of Counterfeiting in Canada, 2013, General Store Publishing House, Renfrew, Ontario. James is a Director of The Historical Society of Ottawa.
